Emmanuel Prouff is a researcher in Applied Cryptography and Embedded Security. He has worked as an expert for ANSSI, France, as well as for major security companies such as IDEMIA and SAFRAN, both to develop secure implementations against physical attacks.

Guénaël Renault is Deputy Head of the Hardware Security Lab at ANSSI, France. His research interests include cryptography, algebraic (symbolic) computation and computational number theory.

Mattieu Rivain is a researcher and entrepreneur in Cryptography, currently working as CEO at CryptoExperts, France. His research interests include provable security against side-channel attacks, white-box cryptography, zero-knowledge proofs and post-quantum signatures.

Colin O'Flynn is Assistant Professor in Embedded Hardware Security at Dalhousie University, Canada. His interests include embedded hardware security, PCB design and prototype construction.

Preface xiii
Emmanuel PROUFF, Guénaël RENAULT, Matthieu RIVAIN and Colin O'FLYNN Part 1 Software Side-Channel Attacks 1 Chapter 1 Timing Attacks 3Daniel PAGE 1.1. Foundations 3 1.1.1. Execution latency in theory 4 1.1.2. Execution latency in practice 5 1.1.3. Attacks that exploit data-dependent execution latency 6 1.2. Example attacks 10 1.2.1. Example 1.1: an explanatory attack on password validation 10 1.2.2. Example 1.2: an attack on xtime-based AES 12 1.2.3. Example 1.3: an attack on Montgomery-based RSA 14 1.2.4. Example 1.4: a padding oracle attack on AES-CBC 17 1.3. Example mitigations 20 1.4. Notes and further references 21 1.5. References 24 Chapter 2 Microarchitectural Attacks 31Yuval YAROM 2.1. Background 31 2.1.1. Memory caches 31 2.1.2. Cache hierarchies 32 2.1.3. Out-of-order execution 33 2.1.4. Branch prediction 34 2.1.5. Other caches 34 2.2. The Prime+Probe attack 34 2.2.1. Prime+Probe on the L1 data cache 35 2.2.2. Attacking T-table AES 36 2.2.3. Prime+probe on the LLC 38 2.2.4. Variants of Prime+Probe 39 2.3. The Flush+Reload attack 41 2.3.1. Attack technique 41 2.3.2. Attacking square-and-multiply exponentiation 42 2.3.3. Attack variants 43 2.3.4. Performance degradation attacks 44 2.4. Attacking other microarchitectural components 45 2.4.1. Instruction cache 45 2.4.2. Branch prediction 46 2.5. Constant-time programming 47 2.5.1. Constant-time select 47 2.5.2. Eliminating secret-dependent branches 48 2.5.3. Eliminating secret-dependent memory access 49 2.6. Covert channels 50 2.7. Transient-execution attacks 51 2.7.1. The Spectre attack 51 2.7.2. Meltdown-type attacks 53 2.8. Summary 54 2.9. Notes and further references 54 2.10. References 57 Part 2 Hardware Side-Channel Attacks 65 Chapter 3 Leakage and Attack Tools 67Davide BELLIZIA and Adrian THILLARD 3.1. Introduction 67 3.2. Data-dependent physical emissions 67 3.2.1. Dynamic power 68 3.2.2. Static power 70 3.2.3. Electro-magnetic emissions 72 3.2.4. Other sources of physical leakages 73 3.3. Measuring a side-channel 75 3.3.1. Power analysis setup 75 3.3.2. Probes and probing methodologies 75 3.4. Leakage modeling 78 3.4.1. Mathematical modeling 78 3.4.2. Signal-to-noise ratio 81 3.4.3. Open source boards 83 3.4.4. Open source libraries for attacks 85 3.5. Notes and further references 86 3.6. References 87 Chapter 4 Supervised Attacks 91Eleonora CAGLI and Loïc MASURE 4.1. General framework 91 4.1.1. The profiling ability: a powerful threat model 91 4.1.2. Maximum likelihood distinguisher 94 4.2. Building a model 98 4.2.1. Generative model via Gaussian templates 98 4.2.2. Discriminative model via logistic regression 100 4.2.3. From logistic regression to neural networks 102 4.3. Controlling the dimensionality 105 4.3.1. Points of interest selection with signal-to-noise ratio 106 4.3.2. Fisher's linear discriminant analysis 107 4.4. Building de-synchronization-resistant models 108 4.5. Summary of the chapter 112 4.6. Notes and further references 113 4.7. References 115 Chapter 5 Unsupervised Attacks 117Cécile DUMAS 5.1. Introduction 117 5.1.1. Supervised attacks 117 5.1.2. Unsupervised attacks 118 5.1.3. How to attack without profiling? 120 5.2. Distinguishers 122 5.3. Likelihood distinguisher 123 5.3.1. Distinguisher definition 123 5.3.2. Determining Gaussian model parameters 125 5.3.3. Linear leakage model for sensitive data 125 5.3.4. Linear leakage model for sensitive data bits 127 5.3.5. Conclusion 128 5.4. Mutual information 129 5.4.1. Information theory 129 5.4.2. Distinguisher 131 5.4.3. Bijectivity 132 5.4.4. Probability calculation 133 5.4.5. Conclusion 135 5.5. Correlation 136 5.5.1. Linear relationship - CPA 136 5.5.2. Equivalence 138 5.5.3. Conclusion 139 5.6. A priori knowledge synthesis 139 5.7. Conclusion on statistical tools 142 5.8. Exercise solutions 144 5.9. Notes and further references 149 5.10. References 150 Chapter 6 Quantities to Judge Side Channel Resilience 153Elisabeth OSWALD 6.1. Introduction 153 6.1.1. Assumptions and attack categories 154 6.1.2. Attack success 155 6.2. Metrics for comparing the effectiveness of specific attack vectors 156 6.2.1. Magnitude of scores 157 6.2.2. Number of needed leakage traces/success rate estimation 157 6.3. Metrics for evaluating the leakage (somewhat) independent of a specific attack vector 158 6.3.1. Signal to noise ratio 158 6.3.2. Mutual information 159 6.4. Metrics for evaluating the remaining effort of an adversary 160 6.4.1. Key rank 160 6.4.2. Average key rank measures 161 6.4.3. Relationship with enumeration capabilities 162 6.5. Leakage detection as a radical alternative to attack driven evaluations 162 6.6. Formal evaluation schemes 164 6.6.1. CC evaluations 165 6.6.2. Fips 140-3 166 6.6.3. Worst-case adversaries 167 6.7. References 167 Chapter 7 Countermeasures and Advanced Attacks 171Brice COLOMBIER and Vincent GROSSO 7.1. Introduction 171 7.2. Misalignment of traces 173 7.2.1. Countermeasures 174 7.2.2. Attacks 179 7.3. Masking 180 7.3.1. Countermeasures 181 7.3.2. Attacks 182 7.4. Combination of countermeasures 183 7.5. To go further 184 7.6. References 185 Chapter 8 Mode-Level Side-Channel Countermeasures 187Olivier PEREIRA, Thomas PETERS and François-Xavier STANDAERT 8.1. Introduction 187 8.2. Building blocks 188 8.3. Security definitions 190 8.3.1. Authenticated encryption and leakage 191 8.3.2. Integrity with leakage 192 8.3.3. Confidentiality with leakage 193 8.3.4. Discussion 195 8.4. Leakage models 197 8.4.1. Models for integrity 198 8.4.2. Models for confidentiality 199 8.4.3. Practical guidelines 201 8.5. Constructions 201 8.5.1. A leakage-resilient MAC 201 8.5.2. A leakage-resistant encryption scheme 204 8.5.3. A leakage-resistant AE scheme 207 8.6. Acknowledgments 208 8.7. Notes and further references 208 8.8. References 210 Part 3 Fault Injection Attacks 213 Chapter 9 An Introduction to Fault Injection Attacks 215Jean-Max DUTERTRE and Jessy CLÉDIÈRE 9.1. Fault injection attacks, disturbance of electronic components 216 9.1.1. History of integrated circuit disturbance 216 9.1.2. Fault injection mechanisms 219 9.1.3. Fault injection benches 245 9.1.4. Fault models and fault injection simulation 253 9.2. Practical examples of fault injection attacks 262 9.2.1. Introduction 262 9.2.2. 1997 light attack on a secure product when loading a DES key 263 9.2.3. Experimental examples of an attack on a PIN identification routine 265 9.3. Notes and further references 272 9.4. References 273 Chapter 10 Fault Attacks on Symmetric Cryptography 277Debdeep MUKHOPADHYAY and Sayandeep SAHA 10.1. Introduction 277 10.2. Differential fault analysis 278 10.2.1. Block ciphers and fault models 278 10.2.2. DFA on AES: single-byte fault 281 10.2.3. DFA on AES: multiple-byte fault 284 10.2.4. DFA on AES: other rounds 285 10.2.5. DFA on AES: key schedule 285 10.2.6. DFA on other ciphers: general idea 286 10.3. Automation of DFA 286 10.3.1. ExpFault 287 10.4. DFA countermeasures: general idea and taxonomy 289 10.4.1. Detection countermeasures 290 10.4.2. Infective countermeasures 291 10.4.3. Instruction-level countermeasures 292 10.5. Advanced FA 292 10.5.1. Biased fault model 293 10.5.2. Statistical fault attack 293 10.5.3. Statistical ineffective fault attack 294 10.5.4. Fault template attacks 296 10.5.5. Persistent fault attacks 301 10.6. Leakage assessment in fault attacks 302 10.7. Chapter summary 305 10.8. Notes and further references 306 10.9. References 307 Chapter 11 Fault Attacks on Public-key Cryptographic Algorithms 311Michael TUNSTALL and Guillaume BARBU 11.1. Introduction 311 11.2. Preliminaries 312 11.2.1. Rsa 312 11.2.2. Elliptic curve cryptography 314 11.3. Attacking the RSA using the Chinese remainder theorem 315 11.4. Attacking a modular exponentiation 316 11.5. Attacking the ECDSA 318 11.6. Other attack strategies 319 11.6.1. Safe errors 319 11.6.2. Statistical ineffective fault attacks 319 11.6.3. Lattice-based fault attacks 320 11.7. Countermeasures 321 11.7.1. Padding schemes 322 11.7.2. Verification, detection and infection 322 11.7.3. Attacks on countermeasures 323 11.8. Conclusion 324 11.9. Notes and further references 325 11.10. References 328 Chapter 12 Fault Countermeasures 333Patrick SCHAUMONT and Richa SINGH 12.1. Anatomy of a fault attack 333 12.2. Understanding the attacker 334 12.2.1. Fault attacker objectives 334 12.2.2. Fault attacker means 335 12.3. Taxonomy of fault countermeasures 336 12.4. Fault countermeasure principles 337 12.4.1. Redundancy 337 12.4.2. Randomness 338 12.4.3. Detectors 339 12.4.4. Safe-error defense 339 12.5. Fault countermeasure examples 340 12.5.1. Algorithm level countermeasures 340 12.6. ISA level countermeasures 342 12.7. RTL-level countermeasures 343 12.8. Circuit-level countermeasures 343 12.9. Design automation of fault countermeasures 344 12.10. Notes and further references 345 12.11. References 348 List of Authors 355 Index 357 Summary of Volume 2 363 Summary of Volume 3 371
