Beschreibung
The 34 chapters of the 2nd edition of How to Gain Gain give a detailed insight into a collection (54) of the most common gain producing, constant current generating possibilities, and electronic noise creation of triodes for audio pre-amplifier purposes. These chapters also offer complete sets of formulae to calculate gain, frequency and phase responses, and signal-to-noise ratios of certain building blocks built-up with this type of vacuum valve (tube). In all cases detailed derivations of the gain formulae are also presented.

All what is needed are the data sheet valve characteristic figures of the triode's mutual conductance, the gain factor and the internal plate (anode) resistance. To calculate frequency and phase responses of gain stages the different data sheet based input and output capacitances have to be taken into account too.

To calculate transfer functions and signal-to-noise ratios for any kind of triode driven gain stage, including all its bias setting, frequency, phase, and electronic noise influencing components, example Mathcad 11 worksheets as an essential simulation tool for each chapter allow easy follow-up and application of the respective formulae. Free download of all worksheets is guaranteed from the editor's web-site or [...] .
The 34 chapters of the 2nd edition of How to Gain Gain give a detailed insight into a collection (54) of the most common gain producing, constant current generating possibilities, and electronic noise creation of triodes for audio pre-amplifier purposes. These chapters also offer complete sets of formulae to calculate gain, frequency and phase responses, and signal-to-noise ratios of certain building blocks built-up with this type of vacuum valve (tube). In all cases detailed derivations of the gain formulae are also presented.

All what is needed are the data sheet valve characteristic figures of the triode's mutual conductance, the gain factor and the internal plate (anode) resistance. To calculate frequency and phase responses of gain stages the different data sheet based input and output capacitances have to be taken into account too.

To calculate transfer functions and signal-to-noise ratios for any kind of triode driven gain stage, including all its bias setting, frequency, phase, and electronic noise influencing components, example Mathcad 11 worksheets as an essential simulation tool for each chapter allow easy follow-up and application of the respective formulae. Free download of all worksheets is guaranteed from the editor's web-site or [...] .
Zusammenfassung

Summary of all the gain producing possibilities of triodes in one place

Shows how to calculate first and spend money for expensive components later

Gain making elements far away from silicon: Vacuum valves and audio transformers

Inhaltsverzeichnis

From the Contents: Basics - Noise in Triodes - Noise in Components and Other General Noise Effects - The Common Cathode Gain Stage (CCS) - CCS Mathcad Worksheets - The Common Anode gain Stage (Cathode Follower CF) - CF Mathcad Worksheets - The Common Grid gain Stage (CGS) - CGS Mathcad Worksheets - The Concertina (Cathodyne) Phase Splitter (CPS) - CPS Mathcad Worksheets - Constant Current Generators (CCG) - CCG Mathcad Worksheets - The Cascode Amplifier (CAS) - CAS Mathcad Worksheets - The Shunt Regulated Push-Pull Gain Stage (SRPP) - SRPP Mathcad Worksheets - The µ-Follower (µF) - µF Mathcad Worksheets - The CCS with Active Anode Load (CCA) - CCA Mathcad Worksheets - The Cascoded Cathode Follower (CCF) - CCF Mathcad Worksheets - The White Cathode Follower (WCF) - WCF Mathcad Worksheets - Triodes In Parallel Operation (PAR) - PAR Mathcad Worksheets - The CCS Followed by a CF (CCSCF) - CCSCF Mathcad Worksheets - Differential Gain Stage (DIF) - DIF Mathcad Worksheets - Feedback (FB) - FB Mathcad Worksheets - Data Sheets and Summaries of Example Gain Stage Calculations (MSC) - Appendices - Index

Details
Erscheinungsjahr: 2016
Fachbereich: Nachrichtentechnik
Genre: Mathematik, Medizin, Naturwissenschaften, Technik
Rubrik: Naturwissenschaften & Technik
Medium: Taschenbuch
Inhalt: xiv
862 S.
536 s/w Illustr.
862 p. 536 illus.
ISBN-13: 9783662501863
ISBN-10: 3662501864
Sprache: Englisch
Einband: Kartoniert / Broschiert
Autor: Vogel, Burkhard
Auflage: Softcover reprint of the original 2nd edition 2013
Hersteller: Springer-Verlag GmbH
Springer Berlin Heidelberg
Verantwortliche Person für die EU: Springer Verlag GmbH, Tiergartenstr. 17, D-69121 Heidelberg, juergen.hartmann@springer.com
Maße: 235 x 155 x 47 mm
Von/Mit: Burkhard Vogel
Erscheinungsdatum: 29.10.2016
Gewicht: 1,299 kg
Artikel-ID: 107672502
