EMC of Analog Integrated Circuits

Um unseren Shop nutzen zu können, müssen Sie Javascript in Ihrem Browser aktivieren.

Dekorationsartikel gehören nicht zum Leistungsumfang.

Sprache: Englisch

135,95 €*

inkl. MwSt.

Versandkostenfrei per Post / DHL

Lieferzeit 4-7 Werktage

Sie können kein Produkt in den Warenkorb legen, da Javascript und technisch notwendige Cookies aktiviert sein müssen.

Kategorien:

Der Artikel ist nicht in deutscher Sprache verfasst.
Die Sprache der Produktbeschreibung und Details kann in Englisch angegeben sein. Sollten Sie Verständnisprobleme haben, wenden Sie sich gerne an uns.

Beschreibung

Environmental electromagnetic pollution has drastically increased over the last decades. The omnipresence of communication systems, various electronic appliances and the use of ever increasing frequencies, all contribute to a noisy electromagnetic environment which acts detrimentally on sensitive electronic equipment. Integrated circuits must be able to operate satisfactorily while cohabiting harmoniously in the same appliance, and not generate intolerable levels of electromagnetic emission, while maintaining a sound immunity to potential electromagnetic disturbances: analog integrated circuits are in particular more easily disturbed than their digital counterparts, since they don't have the benefit of dealing with predefined levels ensuring an innate immunity to disturbances. The objective of the research domain presented in EMC of Analog Integrated Circuits is to improve the electromagnetic immunity of considered analog integrated circuits, so that they start to fail at relevantly higher conduction levels than before.

Zusammenfassung

EMC-aware analog integrated circuit design is domain which is continuously gaining in importance

Paradoxically, literature describing and solving EMC problems in integrated circuits is not widely spread: most EMC-related works describe what should be done outside the integrated circuit (like shielding, etc.). Conversely, this research looks at how EMC incompatibilities can be tackled on-chip

The structure of the book explains how to identify and solve EMC problems in output stages, input stages and power supply terminals by means of practical design cases

The design cases described in this work have been validated with measurements and/or simulations

Last but not least, stressing the first point in this list, the authors strongly believe that EMC problems will keep on increasing in the future

Includes supplementary material: [...]

Inhaltsverzeichnis

Preface. 1. INTRODUCTION. 1 The pioneers of wireless communication. 2 Evolution of awareness of electromagnetic compatibility. 3 Electromagnetic compatibility of integrated circuits. 4 Scope of this book. 2. BASIC EMC CONCEPTS AT IC LEVEL. 1 Introduction. 2 Definition of EMC, EMI, EMS and EME. 3 Sources of electromagnetic interference. 4 Electromagnetism versus integrated circuit design. 5 Intra-chip versus externally-coupled EMC. 6 Analog versus digital integrated circuits. 7 EMC in automotive applications. 8 Immunity measurement methods for IC¿s: IEC 62132. 3. EMC OF INTEGRATED CIRCUITS VERSUS DISTORTION. 1 Introduction. 2 Relationship between EMI resisting design and distortion. 3 Case study 1: diode connected NMOS transistor. 4 Case study 2: NMOS source follower. 5 Case study 3: NMOS current mirror. 6 Case study 4: EMI susceptibility in ESD protections. 7 EMI induced DC shift. 4. EMI RESISTING ANALOG OUTPUT CIRCUITS. 1 Introduction. 2 Categorization of analog output structures. 3 Case study 1: EMI resisting DC current regulator. 4 Case study 2: EMI resisting LIN driver. 5. EMI RESISTING ANALOG INPUT CIRCUITS. 1 Introduction. 2 Case study 1: electromagnetic immunity of CMOS operational amplifiers. 3 Case study 2: EMI resisting instrumentation amplifier input circuit. 6. EMI RESISTING BANDGAP REFERENCES AND LOW DROPOUT VOLTAGE REGULATORS. 1 Introduction. 2 Case study 1: CMOS bandgap voltage references with a high immunity to EMI. 3 Case study 2: EMI resisting low dropout voltage regulators. 7. EPILOGUE. References. Index.

Details

Erscheinungsjahr:	2012
Fachbereich:	Nachrichtentechnik
Genre:	Technik
Rubrik:	Naturwissenschaften & Technik
Medium:	Taschenbuch
Seiten:	256
Reihe:	Analog Circuits and Signal Processing
Inhalt:	x 243 S.
ISBN-13:	9789400730885
ISBN-10:	9400730888
Sprache:	Englisch
Ausstattung / Beilage:	Paperback
Einband:	Kartoniert / Broschiert
Autor:	Steyaert, Michiel Redouté, Jean-Michel
Auflage:	2010
Hersteller:	Springer Netherland Springer Netherlands Analog Circuits and Signal Processing
Maße:	235 x 155 x 15 mm
Von/Mit:	Michiel Steyaert (u. a.)
Erscheinungsdatum:	14.03.2012
Gewicht:	0,394 kg

preigu-id: 106592037
